Imaging: 640×480 IR resolution, 25mK sensitivity (NETD), and 13MP visual camera with autofocus
.
Optics: 180° rotating lens with 0.68mrad IFOV; supports manual, motor, continuous autofocus, and laser-assisted focusing
.
Display: 5” AMOLED touch screen (1280×720) and 1080p color OLED viewfinder
.
Measurement: -20℃ to +600℃ range (extendable to 1700℃); accuracy of ±1°C/1% between 5°C-150°C
.
Analysis Tools: 20 movable spots, 10 rectangular/circular areas, and 10 line measurements
.
Connectivity & Sensors: 64GB storage, Laser Ranging (0.2m-50m), GPS, Compass, WIFI, Bluetooth, and USB Type-C
,
.
Physical: IP54 protection, 4-hour battery life, and ≤1.4kg weight
.
Applications: The device is designed for high-end industrial markets, building diagnostics, electrical/mechanical inspection, R&D, and predictive maintenance
,
.
