Flow range (ml/min) 0.006-2300
Speed range (rpm) 0.1-600
Speed resolution(rpm) 0.1rpm
Advanced Dispensing function.
Flow Rate control.
Flow accuracy <0.5%
Color LCD displaying, touch screen & keypad for operating.
with dispensing mode
Power supply AC 220V ± 10% 50Hz/60Hz (standard); AC 110± 10% 50Hz/60Hz(optional
Power consumption <50W
External control Input level 5V,12V (standard), 24V (optional)
External control analog0-5V (standard), 0-10V, 4-20mA( optional)
Communication interface RS485 communication interface, MODBUS protocol is available.
Operating condition Temperature 0-40°C; Relative humidity <80%
IP grade IP31
Dimensions (LxWxH) 223x150x195 (mm)
Weight 4.9kg
