Flow range (ml/min) 0.006 ~ 2900
Speed range (rpm) 0.1-600
Speed resolution: 0.1rpm/ 1rpm
Flow accuracy <0.5%
Power consumption <50W
External control:
Input electrical level 5V,
12V (standard), 24V (optional)
External control analog 0-5V
(standard), 0-10V, 4-20mA
(optional)
RS485 communication interface
support the MODBUS protocol.
Ambient temp. 0 ~ 40°C
Relative humidity <80%
IP grade IP31
Dimensions (LxWxH) 260mmx181mmx198mm
Weight 4.9KG
