Flow rates：0 ml/min-1500 ml/min
- Speed：0rpm-300rpm，CW/CCW
- Speed resolution：1rpm
- Display：LCD
- Control mode：Keypad control, external signal control and communication control are available
- External control：Start/stop control, direction control: voltage level signal or switch signal are optional.
Speed control: 0-5V,0-10V,4-20mA,0-10kHz are optional with uniform interface, max speed can be set between 30rpm and 300rpm.
- Communication control：RS485 interface, Longer protocol or Modbus protocol, the communication parameters (address, baud rate, parity, stop bit) can be set through keypad.
- Parameter memory：Operating parameters will be saved automatically.
- Pump status when power up：The pump status when power up could be set as stop or as the status before power loss.
- Prime：Fast filling or emptying at full speed
- EMC：Comply with EMC Directive 2014/30/EU
- Keypad lock function：Keypad can be locked to prevent the misoperation. The delay time before lock is settable.
- Dimension(L X W X H)：235mm*142mm*152mm
- Power supply：AC90V-260V/50W，50-60Hz
- Operating temperature：0℃-40℃
- Relative humidity：10%-90%
- IP rating：IP65
- Weight：3.64kg
